Special Tool Manufacturing to Exact Blueprints
When standard catalogue dimensions fall short of your machining requirements, Rock River Tool, Inc. delivers custom-engineered cutting tooling tailored to your part drawings. From non-standard diameters and special step geometries to custom carbide grades and internal coolant channels, our engineering group works directly with procurement teams and manufacturing engineers worldwide.
Custom Tool Engineering Capabilities
Our state-of-the-art grinding room and braze facility produce specialized tools engineered for challenging workpiece materials including hardened steels, ductile iron, high-temp aerospace alloys, and abrasive non-ferrous materials.
- Special Shank Geometries: Weldon flats, reduced shanks, Morse tapers, and custom locking grooves.
- Form & Step Combination: Step reamers, multi-diameter counterbores, dovetail cutters, and porting tools.
- Precision Grinding Tolerances: Micro-inch surface finishes, tight outer diameter tolerances, and controlled corner radii.
- Coolant Delivery Options: Coolant-through the spindle or axial/radial coolant channels for deep-hole chip evacuation.
- Application Carbide Grades: Premium C-2 (883 grade) for non-ferrous materials and C-5/C-6 (370 grade) for steel cutting.
| Tool Category | Customizable Parameters | Primary Applications |
|---|---|---|
| Shank-Type Tools | Diameters, Flute Length, Overall Length, Helix Angles, Chamfers | End Mills, Reamers, Counterbores, Step Drills |
| Slotting & Form Tools | Neck Diameter, Cut Width, Corner Radii (R1/R2), Tooth Style | Keyseat Cutters, Dovetail Cutters, T-Slot Cutters |
| Arbor-Hole Cutters | Cutter OD, Width, Arbor Hole Dia, Keyway, Radii/Chamfers | Side Mills, Slitting Saws, Angle Cutters |
| Port Contour Cutters | Reamer Pilots, Chamfer Angles, Thread Clearance Form | Hydraulic Manifolds, Aerospace Valve Bodies |
Required Parameters for Technical Quotation
To expedite engineering review and receive an accurate quotation for your custom cutting tool, please review the key design parameters below before submitting your inquiry:
1. Shank-Type Tool Geometries
- Shank Diameter (S): Nominal size or precision decimal ground.
- Overall Length (T): Extended reach or compact stub designs.
- Major Diameter (A): Cutting edge diameter and tolerance.
- Flute & Carbide Length (E & F): Length of cut and braze section.
- Hand of Cut & Helix: RH/LH cut, straight, RH/LH spiral angles.
- Feature Options: Step diameters, step angles, minimum cut dia (M).
2. Keyseat, Dovetail & Slotting Cutters
- Neck Diameter (N): Arbor/neck neck-down clearance diameter.
- Cutter Width (W): Precision slotting width and tolerance.
- Dovetail Angle (J): Specific included angle (e.g., 45°, 60°).
- Corner Radii (R1 / R2): Single-side, both sides, or full radius.
- Tooth Form: Straight tooth vs. staggered tooth configuration.
3. Arbor-Hole & Angle Cutters
- Cutter OD & Width (A & W): Outer diameter and face width.
- Arbor Hole (A): Bore size and standard driving keyway (K).
- Hub Diameter (H): Hub clearance and structural reinforcement.
- Angle Cutter Form: Double angle, right-hand angle, or left-hand angle.
- Chamfer & Radius: Specified face chamfers or corner radii.
Why B2B Procurement Teams Choose Rock River Tool
Over four decades of dedicated tooling production in Illinois, USA ensures complete quality control from raw material selection to final edge honing. We serve global buyers across automotive, aerospace, fluid power, and heavy machine manufacturing.
- Direct Engineering Access: Speak directly with tool engineers who evaluate manufacturability and tool life.
- Export-Ready Logistics: Documented heat codes, commercial invoices, and international freight compliance.
- Advanced Coatings: Optional TiN, TiALN, ALTiN, and PVD surface treatments tailored to your coolant environment.
Submit Your Drawing or Specifications
For custom quotations, please prepare your technical drawing, CAD file, or detailed parameter list (including material grade, annual volume, and required delivery date).
Our application engineers will conduct a full manufacturability review and deliver a formal quotation promptly.
Ready to Request a Custom Tool Quote?
Click below to connect directly with our engineering team and submit your blueprint dimensions or tooling specifications.
Send an Inquiry
